Atlantis Compact

Industrial Steam Machine

The Atlantis Compact industrial steam line features two models: one has a 7500 W heating element and the other a 9500 W. Both models can be integrated with a vacuum system that uses a HEPA H13 filter to release perfectly filtered air at the outlet.

Atlantis Compact steam cleaning machines use 4.0 technology to allow constant control over work and maintenance by connecting the machine to Novaltec Group’s digital platform.

The models in this line have boiling water and detergent/disinfectant supplying as standard.

REQUEST INFORMATION

360° Product

The industrial steam line Atlantis Standard has the same features as the smaller line (Atlantis Compact) but differs in the size of the body and the volume of the 29 litre water tank and the 8.5 litre detergent tank.

Atlantis Compact is an industrial steam cleaner that is perfectly suited to medium and large environments, such as mechanical industries to clean lathes, presses, milling machines, or in the food industry for cleaning conveyor belts, workbenches, filters, grates and ventilation ducts.



Technical Data

TECHNICAL DATAATLANTIS COMPACT 7.5ATLANTIS COMPACT 9.5
Power supply400 V - 50/60 Hz400 V - 50/60 Hz
Start-up time8 min8 min
Boiler capacity5 l5 l
Boiler materialAISI 304AISI 304
Boiler power7500 W9500 W
Steam product quantity210 g/min245 g/min
Steam output regulationyesyes
Steam pressure8,0 ± 0,3 Bar8,0 ± 0,3 Bar
Steam boiler temperature180° C180° C
Unlimited autonomyyesyes
Double safety valve PED 19,0/9,5 ± 0,3 Bar9,0/9,5 ± 0,3 Bar
Thermostat200° C200° C
PCB230/12 V230/12 V
Control panel voltage5 V5 V
Power cable lenght10 mt10 mt
Frame materialstainless steel 18/10stainless steel 18/10
Standard wheelsØ 100 mmØ 100 mm
Dimensions660x470x680 mm660x470x680 mm
Weight50 Kg50 Kg
